| Category | ZIP 20 PRO |
|---|---|
| Overall Dimensions (L × W × H) | 1635 × 710 × 939 mm (64.4 × 28.0 × 37.0 in) |
| Net Weight | 28.25 kg (62.3 lb) |
| Gross Weight | 34 kg (75.0 lb) |
| Range | ≈38 km (≈23.6 miles) |
| Ground Clearance | 222 mm (8.74 in) |
| Wheelbase | 1097 mm (43.2 in) |
| Rated Power | 1000 W |
| Peak Power | 1500 W |
| Battery Specification | 48 V 15 Ah, 21700 lithium cells |
| Battery Certification | UN 38.3 / MSDS / UL / EU Regulation (EU) 2023/1542 |
| Display | TFT Display |
| Frame Material | Aluminum Alloy 6061 (AL6061) |
| Rear Swingarm Material | One-piece forged AL6061 aluminum |
| Front Tire | 20" × 2.5 Off-road pattern |
| Rear Tire | 20" × 2.5 Off-road pattern |
| Front Suspension | Air fork with compression & rebound adjustment |
| Front Suspension Travel (Tr) | 120 mm (4.72 in) |
| Rear Suspension | Fastace rear shock |
| Rear Suspension Travel (Tf) | 50 mm (1.97 in) |
| Rear Shock Mounting Width | 190 mm (7.48 in) |
| Front Brake | Ø180 mm hydraulic disc brake (Ø7.1 in) |
| Rear Brake | Ø180 mm hydraulic disc brake (Ø7.1 in) |
Open doors to a growing segment of entry-level adventurers. Explore partnership opportunities and grow your business.
Powered by a 48V 10Ah battery (480 Wh, 21700 cells, 5C) and a motor delivering 1500W peak power and 132 N·m of torque. It provides punchy acceleration for urban adventures and a riding range of up to 38 km (23.6 mi).
Clearly shows battery level (SOC), speed, and assist level. Supports multiple riding parameter settings to customize for different rider preferences.
Front and rear suspensions work in unison, featuring a YST front fork (120 mm travel, air damping) and a Fastace rear spring shock (126 mm travel, rebound adjustment). Engineered to smooth out bumps and keep you in control on city streets and light trails.
Reliable stopping power with linear lever feedback. The package includes Ø180 mm front and rear rotors paired with forged dual-piston calipers, ensuring stable and controlled braking.
Built to handle rugged use, with a reinforced rim structure and spokes, an enlarged motor axle, and a strengthened swingarm. This enhances impact resistance and maintains overall frame rigidity for lasting durability.
Clean, secure, and premium finish that minimizes exposed wiring. Reduces risks of abrasion, mud, and water intrusion, enhancing reliability in various environments while providing a refined appearance.
Same footrest design as electric off-road dirt bikes. High-strength aluminum alloy with wide platform for secure support and grip during standing rides.
Waterproof, dustproof, and durable protection for the charging port (charger: AC 100–240V / DC 54V 3A). Shields from water, mud, and debris, improving long-term durability.
Compatible with GoPro, DJI, or Insta360. Allows quick and secure installation of action cameras to easily capture every moment of the ride.
Net weight 28.25 kg (62.3 lb), ground clearance 222 mm, wheelbase 1097 mm, maximum load 75 kg. Packaging: 147 × 26 × 76 cm, gross weight 34 kg, container loading up to 231pcs/40HQ.
Add a versatile, approachable product to your catalog. Reach out today to access trusted distribution and flexible branding.
The ZIP 20 PRO offers a compact 20″ wheel platform, 1100 mm wheelbase, and 48V 10Ah battery, ideal for riders 160-185 cm tall entering recreational trail riding. Distributors can tap into entry-level adventure segments while complementing higher-tier offerings like the ZIP 24 PRO.
Positioned as a lightweight, maneuverable trail bike, the ZIP 20 PRO allows riders to enjoy off-road experiences safely and comfortably. Its rear suspension, hydraulic brakes, and off-road-inspired design make it an accessible alternative to heavy dirt bikes, giving importers a differentiated SKU for novice riders.
The 20 PRO’s packaging supports up to 231 units per 40HQ, enabling cost-efficient international shipping. The platform leverages the RFN brand’s global recognition for added trust, but also accommodates OEM/private branding, allowing partners to adapt the offering to their market strategy.
